ParticleMaster inspex

LaVision’s ParticleMaster inspex system is especially designed for quality control applications in industrial environments. It serves as a highly integrated laboratory and testing tool for the measurement of size, shape and velocity of spray droplets, particles and grains.
The ParticleMaster inspex combines the advantages of Dynamic Image Analysis (DIA) with an easy-to-use design. When particle properties are important process parameters and have to be monitored in real time or inline, our ParticleMaster inspex systems are the right choice.

ParticleMaster inspex
System Features
  • In-situ particle imaging: size, shape and velocity
  • No sample preparation required
  • Compact self-contained probes and lights
  • Fully factory aligned – no customer calibration needed
  • Includes size and depth-of-field calibration
  • Eye-safe LED operation
  • Splash proof IP54 design

The compact and highly integrated design of the ParticleMaster inspex aims for daily laboratory use and quality control testing. The system is ready to use out of-the-box, splash-proof and eyesafe. A well-defined mechanical interface allows the integration into existing test benches.

Measured Quantities
  • Size, shape, orientation, perimeter of individual particles and droplets
  • Velocity and mass flux from dual frame images
  • Cumulated statistics D10, D32, percentiles Dv10, Dv50, Dv90
  • Size histograms, scatterplots
